500 Jumbo Series LED Stop / Tail Lamp 9 - 33 Volt
Retrofit upgrades with older Jumbo style lamps with a similar base design
Red Illumination
56 x High Intensity White LED's
Faceted Reflectors with Red Polycarbonate pattern free Lens and inbuilt Retro Reflectors
Black ABS Plastic Housing with mounting screws included
Surface Mount- low mounting depth for easy installation
Pre-wired 200mm Lead
Fully encapsulated circuitry
Sealed against Dust and Moisture
ADR 49/00 Rear Stop Lamp specifications approved- CRN 28135 and 28136
ADR 47/00 Reflector specifications approved- CRN 28134
Refer to ADR 13/00 for mounting instructions
IP67 Rating
Box Qty: 1
2 Year Warranty
| Specifications |
| Colour |
Red |
| Type |
LED |
| Shape |
Rectangular |
| Voltage |
Multivolt |
| Beam Type |
|
| Mount |
Surface |
| Width (mm) |
190 |
| Height (mm) |
122 |
| Depth (mm) |
35 |
