CHECK OVERALL LENGTH OF
STARTER AS MAY NOT FIT SOME
THERMOKING APPS WITH
YANMAR ENGINES.
| Specifications |
| Voltage |
12V |
| Kilowatt |
1.2kW |
| Number of Teeth |
9T |
| Pinion Diameter |
29mm |
| Rotation |
CW |
| Pinion at Rest |
17mm |
| Flange Diameter |
89mm |
| Mount Hole Center to Center |
126mm |
| Mount Hole Diameter |
11mm |
| Overall Length |
210mm |
| Oil Sealed |
|
| Series |
PMGR |
| Ground |
NEGATIVE |
| Housing Index |
FIXED |
| Weight (Kg) |
4.0kg |
Cross-reference parts
- AM809215
,- AM879204
,- TY25238
,- AM880978
