Voltage: 12V
Kilowatt: 1.1kw
Number of Teeth: 9T
Pinion Diameter: 29mm
Rotation: CW
Pinion at Rest: 9mm
Flange Diameter: 74mm
Mount Hole Center to Center: 132mm
Mount Hole Diameter: M10- 11mm
Overall Length: 211mm
Oil Sealed
Series
Ground: NEGATIVE
Housing Index: FIXED
Weight (Kg)
Fitment information
Vehicles
- Toyota Corolla 2001 1.8L l4
- Toyota Corolla 2000 1.8L l4
- Toyota Corolla 1999 1.6L l4
- Toyota Corolla 1999 1.8L l4
- Toyota Corolla 1998 1.6L l4
- Toyota Corolla 1998 1.8L l4
- Toyota Corolla 1997 1.6L l4
- Toyota Corolla 1996 1.6L l4
- Toyota Corolla 1995 1.6L l4
- Toyota Corolla 1995 1.8L l4
- Toyota Corolla 1994 1.6L l4
- Toyota Corolla 1994 1.8L l4
- Toyota Corolla 1993 1.6L l4
- Toyota Corolla 1993 1.8L l4
- Toyota Corolla 1992 1.6L l4
- Toyota Corolla 1992 1.8L l4
- Toyota Corolla 1991 1.6L l4
- Toyota Corolla 1990 1.6L l4
- Toyota Corolla 1989 1.6L l4
- Toyota Corolla 1988 1.6L l4
- Toyota Corolla 1987 1.6L l4
Series
*E10*, *E11*, *E9*, AE101R
Chassis numbers
AE101, AE101*, AE102, AE102*, AE112, AE92, AE95
Engine codes
4A-F, 4A-FE, 7A-FE
Cross-reference parts
- 2810087213000
- 2810016041
- 2810016010
- 2810016071
- 2810016070
- 2810087213
- 2810016040
