Description
Specifications | |
Voltage | 12V |
Kilowatt | 0.9kW |
Number of Teeth | 10T |
Pinion Diameter | 28mm |
Rotation | CW |
Pinion at Rest | 12mm |
Flange Diameter | 64mm |
Mount Hole Center to Center | 109mm |
Mount Hole Diameter | M8- 7mm- 9mm |
Overall Length | 195mm |
Oil Sealed | |
Series | |
Ground | NEGATIVE |
Housing Index | FIXED |
Weight (Kg) |
