Description
| Specifications | |
| Voltage | 12V |
| Kilowatt | 0.9kW |
| Number of Teeth | 9T |
| Pinion Diameter | 25mm |
| Rotation | CW |
| Pinion at Rest | -0.5mm |
| Flange Diameter | 66mm |
| Mount Hole Center to Center | 105 x 74 x 73 x 22mm |
| Mount Hole Diameter | M10 |
| Overall Length | 208mm |
| Oil Sealed | |
| Series | |
| Ground | NEGATIVE |
| Housing Index | FIXED |
| Weight (Kg) |
Cross-reference parts
- 8200050150 ,
- 8200466761 ,
- 8200186144 ,
- 8200724817
