PLEASE CHECK PINION AT REST MEASUREMENT. THIS UNIT IS 15mm IF 12mm IS NEEDED USE 70-6122
|
| Specifications |
| Voltage |
12V |
| Kilowatt |
0.8kW |
| Number of Teeth |
8T |
| Pinion Diameter |
28mm |
| Rotation |
CW |
| Pinion at Rest |
16mm |
| Flange Diameter |
74mm |
| Mount Hole Center to Center |
110 x 78 x 78mm |
| Mount Hole Diameter |
M10- 11mm |
| Overall Length |
189mm |
| Oil Sealed |
|
| Series |
|
| Ground |
NEGATIVE |
| Housing Index |
FIXED |
| Weight (Kg) |
