IF REPLACING M0T86981, 70-6054 THERE IS A DIFFERENCE IN MOUNT BOLT SIZING. THIS STARTER USES 2x M10 BOLTS & 1x 11mm BOLT
|
| Specifications |
| Voltage |
12V |
| Kilowatt |
1.4kW |
| Number of Teeth |
10T |
| Pinion Diameter |
27mm |
| Rotation |
CW |
| Pinion at Rest |
6mm |
| Flange Diameter |
76mm |
| Mount Hole Center to Center |
103 x 66 x 66mm |
| Mount Hole Diameter |
M10- 11mm |
| Overall Length |
225mm |
| Oil Sealed |
|
| Series |
|
| Ground |
NEGATIVE |
| Housing Index |
FIXED |
| Weight (Kg) |
Cross-reference parts
- 96481116
,- 5802W4
,- 5802S3
,- 5802V5
,- 5802W9
,- 96253825
,- 5802FJ
,- 5802M7
,- 5802M3
,- 5802W5
,- 9656262780
,- 71719600
,- 71782363
,- 71719608
,- 1342792080
,- 71785219
,- 71716562
,- 71716565
,- 71738330
,- 9625382680
,- 71723361
,- 71719609
,- 71728811
,- 71716563
,- 9625383080
,- 9656299480
,- 71785217
,- 9625382580
,- 71723362
,- M0T20872
,- M1T80082
,- M000T20872ZE
,- 1810A101
,- M001T80082
,- M001T80481
,- M001T80381
,- M0T20871ZE
,- M1T80381
,- M0T86081
,- M0T20871
,- M000T20871
,- M000T20871ZE
,- M000T86081
,- M1T80081
,- M1T80481
,- M0T20872ZE
,- M001T80081
,- 9648111680
,- 5802W8
