CHECK PINION AT REST CLEARANCE
BEFORE FITTING THIS STARTER.
THERE ARE TWO STARTERS TO SUIT
THIS APPLICATION.
ALTERNATE STARTER IS 70-6028
|
| Specifications |
| Voltage |
12V |
| Kilowatt |
1.2kW |
| Number of Teeth |
8T |
| Pinion Diameter |
28mm |
| Rotation |
CW |
| Pinion at Rest |
10mm |
| Flange Diameter |
73mm |
| Mount Hole Center to Center |
98mm |
| Mount Hole Diameter |
M10 |
| Overall Length |
207mm |
| Oil Sealed |
|
| Series |
|
| Ground |
NEGATIVE |
| Housing Index |
FIXED |
| Weight (Kg) |
