Description
CHECK PINION AT REST CLEARANCE
BEFORE FITTING THIS STARTER.
HERE ARE TWO STARTERS TO SUIT
THIS APPLICATION.
ALTERNATE STARTER IS 70-6019
| Specifications | |
| Voltage | 12V |
| Kilowatt | 1.2kW |
| Number of Teeth | 8T |
| Pinion Diameter | 28mm |
| Rotation | CW |
| Pinion at Rest | 18mm |
| Flange Diameter | 73mm |
| Mount Hole Center to Center | 98mm |
| Mount Hole Diameter | M10 |
| Overall Length | 207mm |
| Oil Sealed | |
| Series | |
| Ground | NEGATIVE |
| Housing Index | FIXED |
| Weight (Kg) |
