Jaylec - Starter Motor To Suit Toyota Landcruiser (70-8533)

Voltage: 12V
Kilowatt: 2.5kW
Number of Teeth: 11T
Pinion Diameter: 40mm
Rotation: CW
Pinion at Rest: 14mm
Flange Diameter: 105mm
Mount Hole Center to Center: 145mm
Mount Hole Diameter: M12- 15mm
Overall Length: 298mm
Oil Sealed
Series
Ground: NEGATIVE
Housing Index: FIXED
Weight (Kg)

Fitment information

Vehicles

• Toyota Land Cruiser 1984 3.0L l4
• Toyota Land Cruiser 1984 3.4L l4
• Toyota Land Cruiser 1983 3.0L l4
• Toyota Land Cruiser 1983 3.4L l4
• Toyota Land Cruiser 1982 3.0L l4
• Toyota Land Cruiser 1982 3.4L l4
• Toyota Land Cruiser 1981 3.0L l4
• Toyota Land Cruiser 1981 3.4L l4
• Toyota Land Cruiser 1980 3.0L l4
• Toyota Land Cruiser 1980 3.4L l4
• Toyota Land Cruiser 1979 3.0L l4
• Toyota Land Cruiser 1978 3.0L l4
• Toyota Land Cruiser 1977 3.0L l4
• Toyota Land Cruiser 1976 3.0L l4
• Toyota Land Cruiser 1975 3.0L l4
• Toyota Land Cruiser 1974 3.0L l4
• Toyota Land Cruiser 1973 3.0L l4
• Toyota Land Cruiser 1972 3.0L l4
• Toyota Land Cruiser 1971 3.0L l4
• Toyota Land Cruiser 1970 3.0L l4
• Toyota Land Cruiser 1969 3.0L l4

Series

*J4*, *J5*

Chassis numbers

BJ42*, BJ42*V, BJ45*V, BJ46*, FJ4*, FJ5*

Engine codes

3B, B
